Nā helu huahana:
GE4E a i GE12E
GE15ES a i GE120ES
GE15ES-2RS a i GE120ES
Paʻa Paʻi Paheʻe:Ke kila kila/PTFE
Nā hiʻohiʻona
√ ʻO ke apo o waho he axial seam. ʻO nā apo o loko a me waho i hana ʻia me ke kila kila, kinai ʻia a me ka phosphated, a ua uhi ʻia nā ʻaoʻao sliding me ka molybdenum disulfide. Ma waho aʻe o nā hiʻohiʻona me ka suffix "E", loaʻa nā ʻāpana ʻē aʻe a pau i nā lua lubrication a me nā lua aila i loko a me waho. ʻO nā hiʻohiʻona me ka suffix "-2RS" he mau sila ma nā ʻaoʻao ʻelua o ke apo o waho.
◆ Nā Wehewela Hana: GE...E GE...ES -50 degere a +150 degere
GE...ES-2RS -30 degere a i +130 degere
Hoʻohana nui ʻia nā bearings spherical radial i nā noi aʻe:
ʻO nā bearings maʻemaʻe spherical no nā cylinders hydraulic
01
Axial spherical plain bearings no ka hana ʻana i nā mīkini
02
ʻO nā bearings linear kaumaha -kaumaha a me nā paheʻe no nā mīkini hana hana a me nā mea hana mīkini
03
ʻO nā bearings maʻemaʻe spherical a me nā hopena o ke koʻokoʻo no nā mea hoʻopuʻi kaʻa
04
GE80 spherical plain radial bearings no ka mīkini hydraulic
05
Hiki i nā bearings plain spherical ke kū i nā ukana kaumaha. Ma muli o ko lākou ʻano a me ka hoʻolālā, hiki iā lākou ke kākoʻo i nā ukana radial, nā ukana axial, a i ʻole ka hui pū ʻana o nā ukana radial a axial. No ka mea, ua hookomoia ka ili poepoe waho o ke apo o loko me ka mea i hui pu ia, ua hooluliluli ia keia mau bearings i ka wa hana. Hoʻohana maʻamau ia no ka ʻoni oscillating haʻahaʻa a me ka ʻōwili haʻahaʻa -wikiwiki, a hiki nō hoʻi ke hili i loko o kekahi ʻano kihi. Hiki iā lākou ke hana maikaʻi inā ʻoi aku ka nui o ka misalignment ma waena o ke kumu kākoʻo a me ka lua o ka hale. Hāʻawi ʻo BLH Bearings i nā lawelawe OEM/ODM a hiki ke hana i nā nui maʻamau. E ʻoluʻolu e kelepona mai iā mākou no ka ʻike loea hou aku.
|
Helu Hapai |
Ana mm |
Haawe helu |
he degere |
Kaumaha |
||||||
|
d |
D |
B |
C |
dlmim |
(Cr) |
(Kō) |
||||
|
GE4E |
4 |
12 |
5 |
3 |
6 |
2 |
10 |
16 |
0.0033 |
|
|
GE5E |
5 |
14 |
6 |
4 |
7 |
3.4 |
17 |
13 |
0.0038 |
|
|
GE6E |
6 |
14 |
6 |
4 |
8 |
3.4 |
17 |
13 |
0.0042 |
|
|
GE8E |
8 |
16 |
8 |
5 |
10 |
5.5 |
27 |
15 |
0.0075 |
|
|
GE10E |
10 |
19 |
9 |
6 |
13 |
8.1 |
40 |
12 |
0.011 |
|
|
GE12E |
12 |
22 |
10 |
7 |
15 |
10 |
54 |
10 |
0.015 |
|
|
GE15ES |
GE15ES-2RS |
15 |
26 |
12 |
9 |
18 |
17 |
85 |
8 |
0.027 |
|
GE17ES |
GE17ES-2RS |
17 |
30 |
14 |
10 |
20 |
21 |
106 |
10 |
0.041 |
|
GE20ES |
GE20ES-2RS |
20 |
35 |
16 |
12 |
24 |
30 |
146 |
9 |
0.066 |
|
GE25ES |
GE25ES-2RS |
25 |
42 |
20 |
16 |
29 |
48 |
240 |
7 |
0.119 |
|
GE30ES |
GE30ES-2RS |
30 |
47 |
22 |
18 |
34 |
62 |
310 |
6 |
0.153 |
|
GE35ES |
GE35ES-2RS |
35 |
55 |
25 |
20 |
39 |
80 |
400 |
6 |
0.233 |
|
GE40ES |
GE40ES-2RS |
40 |
62 |
28 |
22 |
45 |
100 |
500 |
7 |
0.306 |
|
GE45ES |
GE45ES-2RS |
45 |
68 |
32 |
25 |
50 |
127 |
640 |
7 |
0.427 |
|
GE50ES |
GE50ES-2RS |
50 |
75 |
35 |
28 |
55 |
156 |
780 |
6 |
0.546 |
|
GE60ES |
GE60ES-2RS |
60 |
90 |
44 |
36 |
66 |
245 |
1220 |
6 |
1.04 |
|
GE70ES |
GE70ES-2RS |
70 |
105 |
49 |
40 |
77 |
315 |
1580 |
6 |
1.55 |
|
GE80ES |
GE80ES-2RS |
80 |
120 |
55 |
45 |
88 |
400 |
2000 |
6 |
2.31 |
|
GE90ES |
GE90ES-2RS |
90 |
130 |
60 |
50 |
98 |
490 |
2450 |
5 |
2.75 |
|
GE100ES |
GE100ES-2RS |
100 |
150 |
70 |
55 |
109 |
510 |
3050 |
7 |
4.45 |
|
GE11OES |
GE110ES-2RS |
110 |
160 |
70 |
55 |
120 |
555 |
3250 |
6 |
4.82 |
|
GE120ES |
GE120ES-2RS |
120 |
180 |
85 |
70 |
130 |
950 |
4750 |
6 |
8.05 |
