LM10UU linear bearings ana:
Anawaena o loko: 10mm
Ka anawaena o waho: 19mm
Loihi: 29mm
Hiki ke hoʻopilikino ʻia nā bearings BLH e like me ka nui o ka mea kūʻai aku. No nā hiʻohiʻona ʻē aʻe, e ʻoluʻolu e nānā i ka papaʻaina nui.
Nā noi o ka LM10UU Linear Bearing
Nā Mea Paʻi 3D
Ma ka paʻi 3D, hiki i nā alakaʻi alakaʻi pōpō linear ke neʻe mālie o ke poʻo paʻi a me ka paepae. He mea koʻikoʻi ka pololei kiʻekiʻe i kēia mau ʻōnaehana, e hana i nā bearings linear motion koʻikoʻi no nā hopena paʻi kūleʻa.
Lako Lapaau a me na Lako
I loko o nā mea lapaʻau a me nā lako hana hoʻokolohua, kōkua pinepine nā bearings pōleʻa e hoʻokō i ka pololei kiʻekiʻe loa i ka neʻe ʻana o ka mea kani ma lalo o nā kūlana sterile. Hoʻohana pinepine ʻia nā bearings laina ʻole-recirculating a i ʻole ma muli o ko lākou haʻahaʻa-hiki i ka haʻahaʻa a me ka mālama haʻahaʻa.
|
Hāpai ʻAʻole. |
Helu No ka Poepoe |
Nā Ana Nui (mm) |
(μm) |
Haawe Kumu Ka helu |
Kaumaha |
|||||||||
|
Kakauia Pōʻai |
Anawaena waho |
Ka lōʻihi |
Puka Laka waho |
W |
Radial Hoʻomaʻemaʻe |
C(kgf) |
Co(kgf) |
g |
||||||
|
ʻO Dr |
D |
Hoʻomanawanui |
L |
Hoʻomanawanui |
B |
Hoʻomanawanui |
D1 |
Max |
||||||
|
LM4UU |
4 |
4 |
8 |
0/-11 |
12 |
0/-0.2 |
0/-0.2 |
-5 |
9 |
13 |
1.9 |
|||
|
LM5UU |
4 |
5 |
10 |
0/-11 |
15 |
0/-0.2 |
10.2 |
0/-0.2 |
9.6 |
1.1 |
-5 |
17 |
21 |
4 |
|
LM6UU |
4 |
6 |
12 |
0/-11 |
19 |
0/-0.2 |
13.5 |
0/-0.2 |
11.5 |
1.1 |
-5 |
21 |
27 |
7.6 |
|
LM8SUU |
4 |
8 |
15 |
0/-11 |
17 |
0/-0.2 |
11.5 |
0/-0.2 |
14.3 |
1.1 |
-5 |
18 |
23 |
10.4 |
|
LM8UU |
4 |
8 |
15 |
0/-11 |
24 |
0/-0.2 |
17.5 |
0/-0.2 |
14.3 |
1.1 |
-5 |
27 |
41 |
15 |
|
LM10UU |
4 |
10 |
19 |
0/-13 |
29 |
0/-0.2 |
22 |
0/-0.2 |
18 |
1.3 |
-5 |
38 |
56 |
29.5 |
|
LM12UU |
4 |
12 |
21 |
0/-13 |
30 |
0/-0.2 |
23 |
0/-0.2 |
20 |
1.3 |
-5 |
42 |
61 |
31.5 |
|
LM13UU |
4 |
13 |
23 |
0/-13 |
32 |
0/-0.2 |
23 |
0/-0.2 |
22 |
1.3 |
-7 |
52 |
79 |
43 |
|
LM16UU |
5 |
16 |
28 |
0/-13 |
37 |
0/-0.2 |
26.5 |
0/-0.2 |
27 |
1.6 |
-7 |
79 |
120 |
69 |
|
LM20UU |
5 |
20 |
32 |
0/-16 |
42 |
0/-0.2 |
30.5 |
0/-0.2 |
30.5 |
1.6 |
-9 |
88 |
140 |
87 |
|
LM25UU |
6 |
25 |
40 |
0/-16 |
59 |
0/-0.2 |
41 |
0/-0.2 |
38 |
1.9 |
-9 |
100 |
160 |
220 |
|
LM30UU |
6 |
30 |
45 |
0/-16 |
64 |
0/-0.3 |
44.5 |
0/-0.3 |
43 |
1.9 |
-9 |
160 |
280 |
250 |
|
LM35UU |
6 |
35 |
52 |
0/-19 |
70 |
0/-0.3 |
49.5 |
0/-0.3 |
49 |
2.1 |
-13 |
170 |
320 |
390 |
|
LM40UU |
6 |
40 |
60 |
0/-19 |
80 |
0/-0.3 |
60.5 |
0/-0.3 |
57 |
2.1 |
-13 |
220 |
410 |
585 |
|
LM50UU |
6 |
50 |
80 |
0/-19 |
100 |
0/-0.3 |
74 |
0/-0.3 |
76.5 |
2.6 |
-13 |
390 |
810 |
1580 |
|
LM60UU |
6 |
60 |
90 |
-0.022 |
110 |
0/-0.3 |
85 |
0/-0.3 |
86.5 |
3.2 |
-16 |
480 |
1020 |
1860 |
